LC Duplex Singlemode 9/125 Fiber Optic Loopback Module

Item No.: Y-FO-FP-011
Fiber Loopback Module is designed to provide a media of return patch for a fiber optic signal. Typically it is used for fiber optic testing applications or network restorations.For the testing applications, the loopback signal is used for diagnosing a pro
INQUIRY
Description Parameters Company Profile Related Product
Description:
Fiber Optic Loopbacks are also called optical loopback adapters. They are designed for testing, engineering and the burnin stage of boards
or other equipment.
Optical loopback adapters provide system test engineers a simple but effective way of testing the transmission capability
and the receiver sensitivity of
network equipment.


Features:
1. Fiber Loopback Module provides a media of return path for a signal, whether the signal is for testing purposes or due to network restoration
2. In the case of testing, the loopback signal is used for diagnosing a problem
3. Sending a loopback test to a network equipment, one at a time, is a technique for isolating a problem
4.The fiber G657.A1 ,G657.A2 Can be chioced. 0.9mm or 2.0mm

Application:
R&D
Fiber labs
Telecom testing
FTTX testing
Equipment interconnection
Device pig-tailing
Premise networks
Patch panel applications
Communications connections
Loopback for network components testing


Ordering information:
Type Fiber Core Cable Type Cable OD Cable Material Cable
Color
Connector
(A End –B End)
Patchcord
Length
PT=Patchcord
PY=Pigtail
S1=G652D
S2= G657A1
M1=50/125
M2=62.5/125
M3=OM3
M4=OM4
S7=G657A1
S8=G657B3
XX=other
01=simplex
02=Duplex
03=Armoured
04=Distribution
05=Ribbon
06=breakout
07=drop cable
XX=other
L=0.9mm
2=2.0mm
3=3.0mm
XX=other


1=PVC
2=LSZH


01=Blue  02=Orange
03=Green  04=Brown
05=Slate  06=White
07=Red  08=Black
09=Yellow  10=Violet
11=Rose  12=Aqua
13=12Color  XX=other
SU=SC/UPC   SA=SC/APC
FU=FC/UPC    FA=FC/APC
LU=LC/UPC    LA=LC/APC
ST=ST/UPC
MPO=MPO/PC  MPA=MPO/APC
00=NONE
XX=Other


0.5M=0.5M
10M=10M
XXX=other



Tags:
Fiber Optic PLC Splitter  | Optical CWDM/DWDM/AWG  | FTTH Drop Fiber Optic Cable  | Fiber Optic PatchCord/jumper/Patch cable  |
Fiber Optic Fast Connector  | Optical Switch  | Fiber Optic Adapter  | Fiber Optic Attenuator  | Fiber Optic Cable TerminalBox |



Optical Specifications:
parameter Singlemode Multimode
Insertion loss(typical) 1.2dB 0.2dB
Insertion loss(Max) 1.5dB 0.7dB
Operating temperature range -20°C to +75°C
Storage temperature range -40°C to +75°C
Repeat Ability < 0.2dB (500 Cycle Passed)
Geometric Specification:
Parameter PC  Polishing APC Polishing
SC Type LC Type
R.O.C 10~25mm 7~25mm 5~12mm
Apex Offset <50um <50um <50um
Fiber Height -125nm-50nm   -100nm-100nm
Polishing Angle     8°± 0.3°
