| Type | Fiber Core | Cable Type | Cable OD | Cable Material | Cable Color |
Connector （A End –B End） |
Patchcord Length |
| PT=Patchcord PY=Pigtail |
S1=G652D S2= G657A1 M1=50/125 M2=62.5/125 M3=OM3 M4=OM4 S7=G657A1 S8=G657B3 XX=other |
01=simplex 02=Duplex 03=Armoured 04=Distribution 05=Ribbon 06=breakout 07=drop cable XX=other |
L=0.9mm 2=2.0mm 3=3.0mm XX=other |
1=PVC 2=LSZH |
01=Blue 02=Orange 03=Green 04=Brown 05=Slate 06=White 07=Red 08=Black 09=Yellow 10=Violet 11=Rose 12=Aqua 13=12Color XX=other |
SU=SC/UPC SA=SC/APC FU=FC/UPC FA=FC/APC LU=LC/UPC LA=LC/APC ST=ST/UPC MPO=MPO/PC MPA=MPO/APC 00=NONE XX=Other |
0.5M=0.5M 10M=10M XXX=other |
| Parameter | Singlemode Patchcord | Multimode Patchcord | ||
| Polishing Type | PC | APC | PC | |
| Insertion loss(dB) | Max. | <=0.7dB | <=0.7dB | <=0.7dB |
| Typical | <=0.35dB | <=0.35dB | <=0.35dB | |
| Return loss(dB) | >=50dB | >=60dB | ≥20dB | |
| Operating temperature | -20ºC~75ºC | |||
| Storage Temperature | -40ºC~75ºC | |||
| 500 mating cycles loss | I.L changed≤0.2dB | |||
| Durability | >1000 cycles | |||
