HDPE MicroDuct, Pre-installed fiber Optic cables, Direct Bury 5mm to 27mm Overall Diameter

HDPE MicroDuct, Pre-installed fiber Optic cables, Direct Bury 5mm to 27mm Overall Diameter

Name: HDPE MicroDuct, Pre-installed fiber Optic cables, Direct Bury 5mm to 27mm Overall Diameter
Brand: OPELINK
SKU: Y-FO-FC-069
Availability: InStock
Rating: 5 (1 reviews)

Item No.: Y-FO-FC-069

Flexible HDPE microduct , Ideal for fiber optic cable installations, last-mile connectivity, and data centers. lightweight for easy installation.

INQUIRY

Description Parameters Company Profile Related product

Description:
Our HDPE MicroDuct offer a compact and reliable solution for installing and protecting micro cables in telecommunications and data center infrastructure.
These tubes are made from high-density polyethylene (HDPE), a robust material offering excellent protection against environmental factors. Their flexible
design allows for easy bending and routing, while their lightweight construction simplifies handling and installation.
Note：The specifications for installing Fiber optic cables inside HDPE MicroDuct shall be in accordance
with customer requirements

Features：
High quality micro cables;
Flexibility and bend radius compatibility;
Durable and protective HDPE material;
Lightweight construction;
various sizes and colors;
Customizable length and thickness.

Application：
primarily in fiber optic cable installations, last-mile connectivity projects, data centers, and smart city infrastructure.

Technical Parameters:
5/3.5mm Series Microduct:

5/3.5mm	O.D. (mm)	Max. Tensile Strength (N)	Weight (kg/km)	Min. Bend Radius (mm)	Crush (N)
1 way	11.8	1000	96	120	2000
2 ways	11.8*16.8	1400	140	160	2000
4 ways	18.9	2000	196	220	2000
7 ways	21.8	2600	255	300	2000
12 ways	27.8	3800	365	380	2000
19 ways	31.8	4800	475	500	2000
24 ways	36.8	6000	610	600	2000

10/8mm Series Microduct:

10/8mm	O.D. (mm)	Max. Tensile Strength (N)	Weight (kg/km)	Min. Bend Radius (mm)	Crush (N)
1 way	16.8	1800	165	210	2000
2 ways	16.8*26.8	2800	258	260	2000
4 ways	30.8	4000	396	500	2000
7 ways	36.8	5500	545	640	2000

12/10mm Series Microduct:

12/10mm	O.D. (mm)	Max. Tensile Strength (N)	Weight (kg/km)	Min. Bend Radius (mm)	Crush (N)
1 way	18.8	2000	190	240	2000
2 ways	18.8*30.8	3000	302	240	2000
4 ways	35.8	4800	467	540	2000
7 ways	42.8	6300	642	750	2000

Note:For more details, please contact our sales
