| Product Type | Fiber Type | Package Dimension | Pigtail Type | Pigtail Length | Connector |
| T5R34=T1550R1310/1490 T4R35=T1490R1310/1550 T3R45=T1310R1490/1550 T34R5=T1310/1490R1550 |
S1=G652D S2=G657A1 |
05=5.5x38mm Steel tube 04=90x20x9.5mm Plastic Box |
B=250um Bare Fiber L=900um Loose Tube 2=2.0mm 3=3.0mm A=Adapter |
05M=0.5M 10M=10M X=Others |
FU=FC/UPC FA=FC/APC SU=SC/UPC SA=SC/APC ST=ST/PC LU=LC/UPC LA=LC/APC 00=None X=Others |
| Parameter | FWDM T4/R35 | FWDM T5/R34 | FWDM T3/R45 | FWDM T34/R5 | |
| Pass Band Wavelength Range (nm)±10 | 1480~1500 | 1540~1560 | 1260~1360 | 1260~1360 & 1480~1500 | |
| Reflection Band 1 Wavelength Range(nm)±10 | 1260~1360 | 1260~1360 | 1480~1500 | 1540~1560 | |
| Reflection Band 2 Wavelength Range (nm)±10 | 1540~1560 | 1480~1500 | 1540~1560 | ||
| Insertion Loss(dB) | Reflect Channel | ≤0.6 | |||
| Pass Channel | ≤0.8 | ||||
| Insertion Loss Variation(dB) | <0.3 | ||||
| Isolation(dB) | Pass Channel | >15 | |||
| Reflect Channel | >30 | ||||
| Inertion Loss Temperature Sensitivity(dB/ºC) | <0.005 | ||||
| Polarization Dependent Loss(dB) | <0.1 | ||||
| Polarization Mode Dispersion(ps) | <0.1 | ||||
| Directivity(dB) | >50 | ||||
| Return Loss(dB) | >50 | ||||
| Maximum Power Handling(mW) | 500 | ||||
| Opterating Temperature(ºC) | -20~+70 | ||||
| Storage Temperature(ºC) | -40~+85 | ||||
